Products
OP3213b PON Optical Power Meter target at the FTTx application and maintenance. This power meter is able
to simultaneously test and estimate the signals of the voice, data and video. It is an essential and ideal tool for
the construction and maintenance of the PON projects.
Features:
* It can experiment at Voice, data and video signal synchronous
measurement and display on BPON/EPON/GPON.
* Providing simultaneous measurement for all three wavelengths on the fiber
(1490nm, 1550nm,1310nm).
* Used in Burst mode measurement of 1310nm upstream.
* Use the software connect with PC, setting the threshold, data transfer, and
calibration the wavelength.
* USB communication port enables data transfer to a PC.1000measurement
items can be saved in PON power meter or computer for data review.
* With optical power meter modual, include 850、1300、1310、1490、1550、
1625sixs(PON Optical Power Meter -AP，PON Optical Power Meter -A
without 850nm wavelength）；With visual fault locator modual（PON Optical Power Meter and PON Optical
Power Meter -AV）
* Optical power meter and VFL with one port.（only PON Optical Power Meter -A）
* Optional Chinese/English display.
* Offers up to 10 different threshold sets in total,Three status LEDs represent different optical signal conditions of
Pass, Warn and Fail respectively.
* 10 minutes Auto-off function can be activated or deactivated
* Good key design,high sensitivity, greatly reducing the volume and weight of the tester.
* Different models corresponding to different function, according to own use to choose .
The 10G PON power meter is suitable for the traditional or next generation PON network testing.
DTH Tester / DVB-S/S2 HD Satellite Finder
OP6966 is a DVB-S/S2 and MPEG-2/4 H.265(8 Bit) compliant handheld satellite meter. With its compact size, light weight, intuitive user’s interface, long battery operational hours and rich feature set, the meter provides all functions needed for installation and verification of digital Satellite TV service to residential homes or multi-dwelling units.
OTM2515/OTM2516/OTM2517 -- 155M/622M/2.5G SDH/SONET Tester
OTM2515 (155M), OTM2516 (622M), and OTM2517(2.5G) SDH/SONET Module is a battery-operated handheld test solution for testing legacy PDH/DSn,SDH/SONET circuits from 2.5Gbps to 2Mbps/1.5Mbps,both in-service and out-of-services, supports overhead monitoring, APS timing etc.
OTM2515 can be upgraded to OTM2516 or OTM2517. OTM2516 can be upgraded to OTM2517.
This module is compatible with OTP6200v2 (OPWILL Intelligent Network Test Platform).
OTM2612 -- 10G Ethernet/SDH/OTN Tester
OTM2612 10G Packet Ethernet/SDH/OTN Test Module is a multi service test solution for the installation and maintenace for Metro/Carrier Ethernet, IP service, SDH/SONET, OTN circuit test up to 10G. Not only does it supply a compact test solution for 10G packet Ethernet, include ITU-T Y.1564 Standard for SLA test features, but also for SDH/SONET supports Out-of Service test, Round Trip Delay, In-service test, overhead controlling and decoding, troubleshooting, APS timing etc.
This module is compatible with OTP6200v2 (OPWILL Intelligent Test Platform).
OTM2620 -- 100G Ethernet/OTN Modulea
OTM2620 100G Test Module is a new modular product, which is released by OPWILL in 2015. This module is designed for satisfying the current increasingly test demand of Core Network and MAN 100GE/40GE and OTU4/OTU3E1/OTU3E2/OTU3 such high speed network performance and stability. This module is compatible with OTP6200v2 (OPWILL Intelligent Network Test Platform).
OTM2800 -- Sync Module (PTP, 1588V2 Tester)
OTM2800 Synchronisation Analyser is specially designed for conducting clock synchronisation of PTN or Packet Ethernet. It is developed in accordance with IEEE1588v2, SyncE, 1PPS+ToD, Ethernet, and E1 such standards, provides a complete clock, frequency, and time synchronisation test solution for operators.
This module is compatible with OTP6200v2 (OPWILL Intelligent Network Test Platform).
OTP6126 -- Handheld Ethernet Test Set
OTP6126 Handheld Gigabit Ethernet Test Set is designed and manufactured by OPWILL, which is specialised in one Gigabit Ethernet network deployment and comprehensive test, and compatible with indoor laboratory and outdoor field environment.
It can fully meet Ethernet standard, support the latest version of ITU-T; Y.1564; IETF RFC2544; IETF RFC3393; IEEE 802.3; IEEE802.1 standards or recommendations and so on.
OTT10-LS -- Optical Light Source
OTT10-LS Series Optical Light Source. Portable design and light weight provide huge benefits and convenience for the engineer to detect optical fibres or cables in core, metro, and access network with high flexibility, and efficiency.
OTT10-PM -- Optical Power Meter
OTT10-PM series Optical Power Metre. Portable design and light weight provide huge benefits and convenience for the engineer to detect optical fibres or cables in core, metro, and access network with high flexibility, and efficiency.
PDA is a smart handheld terminal that fits into your pocket, and it includes all the features you need. What is the PDA? It's a smart phone, a camera, a computer, ID card reader, a high-definition simulation TV, a Gigabit broadband network speedometer, a scan code gun, an optical power meter, a Visual fault locator, a troubleshooting standard ONU, a broadband TV tester, a Wi-Fi tester, a cable tracker and It's a cable threader.
PFS-220T Fusion splicer is used for joining two optical fibers end-to-end using heat, to fuse the two fibers together in such a way that light passing through the fibers is not scattered or reflected back by the splice, and so that the splice and the region surrounding it are almost as strong as the virgin fiber itself.
